ARB on-Board Air Compressor CKMA12 12V
The high-performance CKMA12 ARB compressor can be used to activate the air locks and to pump wheels. Compressor engine has a new type of electronic protection against overheating that automatically shuts off the compressor. Compressor special handle enables the assembly to be rotated 180 degrees.
Kit includes: compressor, air filter, mounting bracket, pressure switch, electrical switch for cabin car and complete electrical harness for front and rear air lock.
- Secure payment by card
- E-mail us, we reply swiftly!
- These rows can be edited \*
\* Edit these rows under Content > Product page
Description
Article no.: CKMA12
Overload protection in harness: yes
Overhead protection of compressor engine: yes
Dimensions (H x L x W): 145 x 190 x 98 [mm]
Weight: 4.5 kg
Power supply: 12 V
Power consumption:
- no load: 14.2 A
- under load: 25.2 A
Efficiency:
- no load: 87.2 l / min.
- under load: (at 200kPa) 65.9 l / min.
Efficiency duty cycle: 50%
